YZP Series Inverter and vector induction motors for Crane and Metallurgical Applications
Features
Good overload capacity and strong mechanical strength
Stepless speed regulation, wide speed regulation range
Energy-saving
Insulation material that can resistant high frequency impulse voltage
Separated blower for forced cooling air
Circumstance for use: Altitude not exceeds 1000m above sea level. The ambient temperature shall no higher than 40℃ and no lower than -15℃; in metallurgy environment the highest temperature shall not higher than +60℃.
Application
Used in the metallurgy and mine industry for driving type crane and similar equipment, especially suit for the instruments which have significant vibration or need short-term and intermittent operation, frequent start and brake, overload.
Performance Data
Common frame size corresponding to the power:
Remark: For the other special rated powers, please contact with us.
